Main material and finish: Black painted (high salt mist resistant) ZDC housing, handle, stainless steel cam
Application: Handle quarter-turn, oneway locked stroke is 22mm, 3 point locked, without changing the structure, you can open the door either RH or LH by changing the direction of the position device, changing the part of electronic box, the electronic lock can become the mechanism lock
Remarks: Default key K043
Electronic Lock Instruction:
When power on, the green signal starts to shine and the handle is not opened (if power off in this time, the lock can be locked automatically ). Push the circular position on swinghandle , the swing handle will bounce from lock body to realize the open function. The power will keep on for 30 seconds. (The time can be set by the customers and we suggest that no longer than 1 min). While you press the swing handle down into the lock body, the power is also cut off to realize the locked function. If there is an accident(for example: remote control is failed, power line is burned and so on) which is supplied without power, please use the mechanism opening method. The open method of mechanism lock: using the special tool to rotate the pentagonal screw and open the dust proof cover, then open the insert by key (the swing handle will bounce to open).
Change the angle of the position device to realize LH or RH
Electronic box instruction: Input voltage rating 12V-24V, current rating 200mA~300mA/DC.
Red line: positive, Blue line: negative ,Green and yellow: signal line.
